| Remark/Примечание | ||
| Material Текстура материала |
9SICR、4241M2、M35 | |
| Appearance Наруж. поверхно сть |
primary color, Titanium Plated(yellow surface),Nitrided(blacksurface),HNS-TIALN (blue-purple surface) Основной цвет, титановое покрытие (поверхность желтая), азотирование (поверхность черная), HNS-TIALN (поверхность сине-фиолетовая) |
|
| Product Item Номер продукта |
Size Номер продукта |
Overall Length спецификация |
Flute Length полная длина, длина резьбы |
Shank Diameter диаметр ручки |
| XD-3520010 | M1X0.25 | 32 | 5.5 | 2.5 |
| XD-3520011 | M1.1x0.25 | 32 | 5.5 | 2.5 |
| XD-3520012 | M1.2x0.25 | 32 | 5.5 | 2.5 |
| XD-3520013 | M1.4x0.3 | 32 | 7 | 2.5 |
| XD-3520014 | M1.6x0.35 | 32 | 8 | 2.5 |
| XD-3520015 | M1.7 x 0.35 | 32 | 8 | 2.5 |
| XD-3520016 | M1.8x0.35 | 32 | 8 | 2.5 |
| XD-3520017 | M2x0.4 | 36 | 8 | 2.8 |
| XD-3520018 | M2.2x0.45 | 36 | 9 | 2.8 |
| XD-3520019 | M2.3x0.4 | 36 | 9 | 2.8 |
| XD-3520020 | M2.5x0.45 | 40 | 9 | 2.8 |
| XD-3520021 | M2.6x0.45 | 40 | 9 | 2.8 |
| XD-3520022 | M3x0.5 | 40 | 11 | 3.5 |
| XD-3520023 | M3.5x0.6 | 45 | 13 | 4 |
| XD-3520024 | M4x0.7 | 45 | 13 | 4.5 |
| XD-3520025 | M4.5x0.75 | 50 | 16 | 6 |
| XD-3520026 | M5x0.8 | 50 | 16 | 6 |
| XD-3520027 | M6x1 | 50 | 19 | 6 |
| XD-3520028 | M7x1 | 50 | 19 | 6 |
| XD-3520029 | M8x1.25 | 56 | 22 | 6 |
| XD-3520030 | M9x1.25 | 63 | 22 | 7 |
| XD-3520031 | M10x1.5 | 70 | 24 | 7 |
| XD-3520032 | M11x1.5 | 70 | 24 | 8 |
| XD-3520033 | M12x1.75 | 75 | 29 | 9 |
| XD-3520034 | M14x2 | 80 | 30 | 11 |
| XD-3520035 | M16x2 | 80 | 32 | 12 |
| XD-3520036 | M18x2.5 | 95 | 40 | 14 |
| XD-3520037 | M20x2.5 | 95 | 40 | 16 |
| XD-3520038 | M22x2.5 | 100 | 40 | 18 |
| XD-3520039 | M24x3 | 110 | 50 | 18 |
| XD-3520040 | M27x3 | 110 | 50 | 20 |
| XD-3520041 | M30x3.5 | 125 | 56 | 22 |
| XD-3520042 | M33x3.5 | 125 | 56 | 25 |
| XD-3520043 | M36x4 | 150 | 63 | 28 |
| XD-3520044 | M39x4 | 150 | 63 | 32 |
| XD-3520045 | M42x4.5 | 150 | 63 | 32 |
| XD-3520046 | M45x4.5 | 160 | 70 | 36 |
| XD-3520047 | M48x5 | 180 | 75 | 36 |
| XD-3520048 | M52x5 | 180 | 75 | 40 |
| XD-3520049 | M56x5.5 | 200 | 85 | 45 |
| XD-3520050 | M64x6 | 200 | 85 | 45 |
| XD-3520051 | M60x5 | 220 | 90 | 50 |
| XD-3520052 | M68x6 | 200 | 90 | 50 |
